CUT WIRES SHOT
CUT WIRES SHOT
CapCut: CapCut is as cut wire shots manufactured by Capstone Abrasives Company with standard process. We manufacture diverse grades as per industries & applications.
CapCCut: CapCCut is conditioned cut wire shot manufactured by Capstone Abrasives Company with standard process, called conditioning. This grade has round edges with semi-cylindrical shape.
CapSpCut: CapSpCut is spherical conditioned cut wire shot manufactured by Capstone Abrasives Company with standard process, called double spherical conditioning. This grade has round edges with semi-round shape.
CapCut Features: (A good replacement of steel grit)
- Sharp-Edge Cut
- Uniform Size & Length
- 100% Free From shear cracks & laps
- Uniform Hardness & Toughness
| TEST CHEMISTRY | SPECIFICATION |
|---|---|
| CARBON | 0.45 - 0.85 % |
| MANGANESE | 0.30 - 1.30 % |
| SILICON | 0.10 - 0.35 % |
| SULPHUR | 0.05 % MAX |
| PHOSPHORUS | 0.04 % MAX |
| FERROS | REMAINDER |
| ATTRIBUTE | SPECIFICATION |
|---|---|
| SHAPE | Cylindrical, Semi-Cylindrical with Round Edges, Semi-Spherical with Round Edges |
| HARDNESS | 45-52 HRC, 55-62 HRC |
| Sp. Gravity | >7.0 G/CM³ |
| Bulk Density | >4.0 G/CM³ |
| MICROSTRUCTURE | TEMPERED MARTENSITE |
| Melting Point | 1535°C |
| Grades | Type | Apply For |
|---|---|---|
| CapCut ? | Cylindrical | For Surface Cleaning & Preparation |
| CapCCut ? | Semi-Cylindrical with Round Edges | For Foundry Industry (Peening) |
| CapSpCut ? | Semi-Spherical with Round Edges | For Specific Industries like Aerospace, Automotive, & Medical |
| Standard | Code |
|---|---|
| IS 5873 | SAE J441 |
| ISO 11124-5 | SAE AMS 2431/3 |
| DIN 8201-4 | SAE AMS 2431/8 |
| VDFI 8001 | - |
